Crosby® S-279 Metric Machinery Eyebolts

Crosby  |  Part # 1045753
$22.06

Crosby® S-279 Metric Machinery Eyebolts are ideal for heavy-duty rigging and lifting applications requiring high-strength, stable connections. They feature heat-treated alloy steel construction for extra strength and durability.

  • Forged steel, quenched and tempered
  • Fatigue rated at 1-1/2 times the Working Load Limit at 20,000 cycles
  • Meets or exceeds all requirements of ASME B30.26
  • Recommended for in-line pull
  • Metric threaded
Save Product
Crosby® S-279 Metric Machinery Eyebolts
Crosby

Crosby® S-279 Metric Machinery Eyebolts

From $22.06

Crosby® S-279 Metric Machinery Eyebolts are ideal for heavy-duty rigging and lifting applications requiring high-strength, stable connections. They feature heat-treated alloy steel construction for extra strength and durability.

Thread Size

  • M6 x 13 --- 200 kg WLL
  • M8 x 13 --- 400 kg WLL
  • M10 x 17 --- 640 kg WLL
  • M12 x 20.5 --- 1000 kg WLL
  • M16 x 27 --- 1800 kg WLL
  • M20 x 30 --- 2500 kg WLL
  • M24 x 36 --- 4000 kg WLL
